Solar Shock vs. Arc Flash Hazards: Understanding the Two Biggest Electrical Dangers in Solar PV Systems

Solar photovoltaic (PV) systems expose workers to two of the most serious electrical hazards in the industry: electric shock and arc flash. While these hazards often occur in the same environment, they are fundamentally different, require different protective measures, and can cause very different types of injuries.

Understanding the difference between electrical shock and arc flash is critical for solar installers, electricians, maintenance technicians, inspectors, and emergency responders working around energized photovoltaic systems.

Proper training, safe work practices, personal protective equipment (PPE), and insulated tools all play an important role in reducing these risks — but only when the right controls are applied to the right hazard. For an overview of all common PV electrical hazards, see Common Solar Electrical Hazards.

Understanding Electric Shock

Electric shock occurs when electrical current passes through the human body.

In a solar PV system, this typically happens when a worker contacts an energized conductor while simultaneously touching another conductor or a grounded surface, completing an electrical circuit.

Because solar panels generate electricity whenever exposed to sunlight, portions of the system may remain energized even after the utility supply has been disconnected, the inverter has been shut down, or disconnect switches have been opened. The conductors between the modules and the first disconnecting means may still carry hazardous DC voltage.

Common sources of electrical shock in PV systems include:

  • Exposed DC conductors
  • Damaged insulation
  • Loose electrical connections
  • Open combiner boxes
  • Inverter terminals
  • Disconnect switches
  • Battery storage systems
  • Improperly handled MC4 connectors

How Electric Shock Injures the Body

The severity of an electrical shock depends on several factors, including:

  • Voltage
  • Current (amperage)
  • Duration of contact
  • Current path through the body
  • Skin condition (dry or wet)
  • Individual health conditions

Electrical shock can cause:

  • Muscle contractions
  • Loss of motor control
  • Respiratory paralysis
  • Internal tissue damage
  • Severe burns at contact points
  • Cardiac arrhythmias
  • Ventricular fibrillation
  • Cardiac arrest

Even relatively small amounts of current passing through the chest can be fatal under the right conditions. Wet skin, fatigue, and extended contact duration all increase injury severity.

Why PV DC Voltage Creates Serious Shock Hazards

Photovoltaic systems generate direct current (DC), which behaves differently from alternating current (AC) in several ways relevant to shock risk.

DC voltage does not pass through zero many times per second as AC does. This means:

  • Sustained muscle contraction may be more pronounced
  • The body cannot release energized equipment as easily
  • Contact duration tends to be longer, increasing injury severity

Large commercial and utility-scale arrays may operate at several hundred volts DC — some exceeding 1,000 volts — making the shock hazard from a single inadvertent contact potentially fatal. Even smaller residential-scale string voltages are well above thresholds associated with serious injury.

Critically, utility disconnection does not stop PV generation. Inverter shutdown does not automatically eliminate upstream DC voltage. Opening a disconnect does not eliminate voltage on its source side. Workers must verify the absence of voltage using properly rated test equipment before assuming any conductor is safe to contact.

Understanding Arc Flash

An arc flash is an entirely different hazard from electric shock.

Instead of electrical current flowing through a person, an arc flash occurs when electricity jumps through the air between energized conductors, or from a conductor to ground. This electrical arc releases enormous amounts of energy in milliseconds — a worker does not have to touch energized equipment to be severely injured by an arc flash.

An arc flash can produce:

  • Temperatures exceeding 35,000°F (approximately 19,400°C) — hotter than the surface of the sun
  • Intense ultraviolet and infrared radiation capable of causing vision damage
  • Molten metal droplets
  • Flying debris and shrapnel
  • Pressure waves (arc blast) that can throw workers and damage hearing
  • Toxic vaporized metal fumes
  • Severe, deep thermal burns

For a comprehensive guide to arc flash hazards, causes, and PPE requirements, see Arc Flash Protection: Causes, Hazards, PPE, and Safe Work Practices.

Why DC Arcs in PV Systems Behave Differently

Arc flash hazards in PV systems carry an additional complication: DC arcs do not naturally self-extinguish the way AC arcs can.

In AC systems, voltage crosses zero many times per second, which naturally tends to interrupt electrical arcs. DC voltage is continuous — there is no natural zero-crossing — which means:

  • DC arcs can persist much longer than AC arcs of similar voltage
  • They are more difficult to interrupt once established
  • They generate intense, sustained heat
  • Conventional AC-rated switching devices may not safely interrupt DC circuits

Conditions capable of initiating or sustaining DC arcs in PV systems include:

  • Loose or improperly torqued electrical connections
  • Incompatible, damaged, or improperly mated MC4 connectors
  • Damaged conductor insulation
  • Ground faults in ungrounded or high-impedance grounded systems
  • Equipment faults within combiner boxes, disconnects, or inverters
  • Conductive tools contacting energized terminals
  • Improper live-circuit switching with inadequate equipment

Potential arc flash locations in PV systems include combiner boxes, DC disconnects, AC disconnects, inverters, service equipment, and battery storage systems.

Rapid Shutdown Does Not Eliminate Arc Flash Risk

Modern PV installations required by NEC Article 690 to include rapid shutdown equipment are designed to reduce hazardous voltages in specified portions of the installation — primarily to improve emergency responder safety outside the array boundary.

However, rapid shutdown does not establish an electrically safe work condition. Workers should understand that:

  • Rapid shutdown does not eliminate all voltage within the PV array
  • Certain conductors and components may remain energized after activation
  • Arc flash hazards may persist in equipment that remains energized
  • Voltage must always be verified before work begins regardless of rapid shutdown status

For a complete treatment of rapid shutdown systems, their capabilities and limitations, see Rapid Shutdown Systems and Emergency Response.

Why Solar Systems Present Unique Risks for Both Hazards

Conventional electrical systems can often be fully de-energized by isolating the utility supply. PV systems cannot — the source of energy is permanently mounted on the structure and continues producing electricity whenever illuminated. This has direct implications for both shock and arc flash:

  • Modules generate DC whenever sufficient light is present — including overcast days, dawn, dusk, and reflected or diffuse light
  • Utility disconnection does not stop PV generation — array-side conductors remain energized
  • Inverter shutdown does not automatically eliminate upstream DC voltage
  • Opening a disconnect does not eliminate voltage on its source side
  • Damaged modules or conductors may remain energized and create arc initiation points
  • Multiple strings and arrays can complicate the electrical condition
  • Battery Energy Storage Systems (BESS), where present, represent an independent energy source that may remain energized after PV production has been reduced — see Battery Energy Storage System (BESS) Electrical Safety

Comparing Shock and Arc Flash: Key Distinctions

Factor Electric Shock Arc Flash
Hazard mechanism Current passes through the body Electricity jumps through the air; energy releases explosively
Contact required? Typically yes — contact with energized part required No — worker can be injured without touching equipment
Primary injuries Internal burns, cardiac arrhythmia, respiratory failure, cardiac arrest External thermal burns, blast injuries, hearing damage, vision damage
PV-specific contributors Exposed DC conductors, damaged connectors, persistent energization, wet conditions Loose connections, damaged connectors, faults, improper switching, DC arc persistence
Why de-energization matters Eliminates the source of current through the body Eliminates the energy source capable of sustaining an arc
PPE approach Voltage-rated rubber insulating gloves, insulated tools, shock-rated face protection Arc-rated clothing, arc-rated face shield, arc flash suit for higher-energy tasks — selected after hazard assessment
Can coexist? Yes — a single task may present both hazards simultaneously; controls for one do not substitute for controls for the other

Note: Specific incident energy values, approach distances, and PPE categories must be determined through a proper hazard assessment following NFPA 70E. The table above describes general distinctions only and does not substitute for a site-specific arc flash risk assessment.

Where Shock and Arc Flash Coexist

These hazards are not mutually exclusive. A single work task — such as opening a DC combiner box on an energized PV system — may simultaneously present:

  • A shock hazard from energized terminals the worker could contact
  • An arc flash hazard if a fault or improper tool contact initiates an arc

Controlling one hazard does not eliminate the other. A worker wearing rubber insulating gloves for shock protection is not automatically protected against arc flash. A worker wearing arc-rated clothing for thermal protection is not automatically protected against the shock hazard from contact with energized parts.

This is why NFPA 70E emphasizes hazard identification and a complete risk assessment before any task — and why de-energization and the establishment of an electrically safe work condition remain the preferred approach whenever feasible.

The Hierarchy of Controls: De-Energize First

Neither shock nor arc flash protection should begin with PPE. Both OSHA and NFPA 70E establish a hierarchy of controls that prioritizes eliminating the hazard before relying on protective equipment:

  1. Elimination — Establish an electrically safe work condition: de-energize, lockout/tagout, and verify absence of voltage
  2. Substitution / Engineering controls — Arc flash mitigation equipment, remote racking, barrier guarding
  3. Administrative controls — Written procedures, qualified personnel, hazard assessments, job briefings
  4. PPE — Last line of defense; selected based on documented hazard assessment

For PV systems, establishing an electrically safe work condition is more complex than in conventional installations because of persistent generation — but the goal remains the same. For the proper shutdown sequence, see Safe Shutdown Procedures for PV Systems.

Common Causes of Solar Electrical Shock

Workers are most likely to experience shock when:

  • Servicing energized equipment without verifying absence of voltage
  • Disconnecting connectors under load
  • Working on damaged wiring with degraded insulation
  • Contacting exposed terminals in open enclosures
  • Performing troubleshooting on energized circuits
  • Working during wet conditions with reduced body resistance
  • Bypassing or skipping lockout/tagout procedures

Common Causes of Solar Arc Flash

Arc flash incidents often result from:

  • Loose or inadequately torqued electrical connections
  • Damaged, incompatible, or improperly mated connectors
  • Equipment failure or insulation breakdown
  • Conductive tools contacting energized parts
  • Incorrect testing or switching procedures on energized circuits
  • Human error during maintenance or commissioning
  • Ground faults in certain PV system configurations

Protecting Against Electric Shock

The preferred approach is to eliminate the hazard by establishing an electrically safe work condition. When energized work is justified and authorized, protection measures include:

  • Following Lockout/Tagout procedures — see Lockout/Tagout for Solar Installations
  • Verifying absence of voltage using properly rated CAT III or CAT IV test equipment
  • Wearing voltage-rated rubber insulating gloves with leather protectors
  • Using IEC 60900 certified 1000V insulated hand tools to reduce the risk of accidental short circuits when working near energized conductors
  • Keeping equipment and work areas dry
  • Inspecting PPE and tools before every use

Insulated tools provide an additional layer of protection against accidental contact with energized parts and reduce the likelihood of initiating a short circuit — but they do not authorize energized work and do not replace the requirement to establish an electrically safe work condition whenever feasible. Learn more about the standard governing insulated tools: IEC 60900: The International Standard for Insulated Hand Tools.

Protecting Against Arc Flash

Reducing arc flash risk requires:

  • Performing a documented arc flash risk assessment per NFPA 70E before energized work
  • Establishing an electrically safe work condition whenever feasible
  • Wearing arc-rated clothing appropriate for the incident energy determined by the assessment
  • Using arc-rated face shields, head protection, and arc flash PPE kits as specified
  • Maintaining proper working distances from potential arc sources
  • Following manufacturer maintenance procedures for connections and torque specifications
  • Keeping electrical equipment properly maintained and connections properly torqued

For a complete guide to arc flash hazards, incident energy, and PPE selection, see Arc Flash Protection: Causes, Hazards, PPE, and Safe Work Practices.

Battery Energy Storage Systems Increase Both Risks

Battery Energy Storage Systems (BESS) can significantly increase both electric shock and arc flash hazards in hybrid solar installations.

Battery systems may remain energized and capable of delivering high fault currents even after PV production has been reduced. This makes them an independent energy source that must be addressed in any shutdown or lockout procedure.

For dedicated BESS safety guidance, see Battery Energy Storage System (BESS) Electrical Safety.

The Role of Insulated Tools

Properly rated 1000V insulated hand tools meeting IEC 60900 help reduce the likelihood of accidental short circuits and minimize the risk of electric shock when working near energized conductors before an electrically safe work condition has been fully established.

However, insulated tools do not eliminate arc flash hazards. Workers must still:

  • Conduct a proper arc flash risk assessment
  • Wear appropriate arc-rated PPE as determined by that assessment
  • Follow NFPA 70E safe work practices
  • Prioritize de-energization over reliance on any single protective measure

Emergency Responder Awareness

Firefighters and other emergency responders approaching PV installations should be aware that energized rooftop arrays may present both shock and arc flash conditions during daylight hours — including during active fire conditions.

Rapid shutdown systems, where installed, are intended to reduce voltages in specified portions of the system to improve responder safety, but do not eliminate all hazards. Responders should follow department protocols and not assume the system is de-energized. For dedicated responder guidance, see Rapid Shutdown Systems and Emergency Response and Solar Electrical Safety for First Responders.

Best Practices for Solar Electrical Safety

Every solar technician should:

  • Treat every PV system as energized until voltage absence is verified
  • Verify the absence of voltage before beginning work — never rely on switch position, indicator lights, or inverter displays alone
  • Understand and address both DC and AC hazards
  • Complete a hazard assessment before performing energized work
  • Wear task-appropriate, properly selected PPE
  • Use insulated tools designed and rated for electrical work
  • Follow OSHA requirements
  • Comply with NFPA 70E safe work practices — see NFPA 70E Explained: Electrical Safety in the Workplace
  • Install systems in accordance with NEC Article 690
  • Stay current with manufacturer recommendations and training

Conclusion

Electric shock and arc flash are two distinct but equally serious hazards found in solar photovoltaic systems. Electric shock occurs when current passes through the body — typically requiring direct contact with an energized part. Arc flash is an explosive release of electrical energy that can cause devastating burns without any direct contact at all.

Because solar panels continue generating DC electricity whenever illuminated, neither hazard disappears simply by opening a disconnect, shutting down an inverter, or isolating utility power. Both hazards require their own recognition, assessment, and controls — and protecting against one does not automatically protect against the other.

Combining de-energization whenever feasible, proper hazard assessment, task-appropriate PPE, qualified personnel, compliance with OSHA and NFPA 70E, and the use of correctly rated insulated tools and test equipment helps create the safest possible conditions for everyone working around photovoltaic systems.
